Features:
1.With intelligent, humanization and high automatic operation, this machine can make the operator mach more
easier for handing all. Any people can learn in one to three hours for operation, can save cost of labors.
2.With Auto-nesting software,just input material’s size, computer can automatic nesting, and generate G Code.
It can save time, with high utilization rate of plate and zero error.
3.Double layer vacuum table can hold small pieces for excellent cutting, realize all kinds of customary cabinet.
4.With hard steel structure, the machine is fit for cutting and engraving on rosewood, MDF, plywood,for furniture,
indoor decoration, and it is qualified for mass-producing of furniture with the vacuum holding way and dust collector.
Performance Parameter:
NO. |
Description |
Parameter |
1 |
X,Y,Z Traveling |
1300*2500*200mm |
2 |
Table Size |
1360×2940mm |
3 |
Table Structure |
Double Layer Vacuum Table |
4 |
Frame |
Welded Structure |
5 |
X,Y,Z Drive System |
XY Helical Rack and Pinion, Z Ball Screw |
6 |
Max Rapid |
30000mm/min |
7 |
Max Working Speed |
15000mm/min |
8 |
Spindle Power |
6.0KW |
9 |
Spindle Speed |
0-18000RPM |
10 |
Driving System |
Stepper System |
11 |
Working Voltage |
AC380V, 50/60HZ, 3PH (Option: 220V) |
12 |
Command Language |
G Code |
13 |
Operating System |
NC studio |
14 |
Software |
Type3, Artcame, UG |
15 |
Gross Weight |
1800KG |
16 |
Options |
Yaskawa Servo Motors |
Syntec Control system |
Guarantee & After Sales Service
1. The machine is guaranteed for 12 months.
2. Technical support by phone, e-mail or MSN around the clock.
3. Friendly English version manual and operation video CD disk.
