3 axis CNC Router-industry

3 AXIS CNC ROUTER INDUSTRY RCH2540

3 AXIS CNC ROUTER INDUSTRY RCH2540
  • No.:1000247391
  • Brand :ROCTECH
  • Weight:7500KG

3 AXIS CNC ROUTER INDUSTRY RCH2540,Detailed

Features:

CNC Router RCH2540 Polystyrene processing center. Four-row imported ball bearing, widening linear lead rail,

self-lubricating block. when engraving, equal force in all directions, to ensure the accuracy and strength.

The route of Z axis can be heightened to 700mm,processing,large format, suitable for processing large-scale

super-thick material.Intelligent processing cross-border protection, the design documents to prevent excessive

hours due to mechanical impact.Diversified control processing speed can be controlled separately, the speed of idle

 running and roll setting, greatly improved the quality of processed products and processing efficiency.

Die and mold industries:
sculpture various large non-metallic mold can be particularly  suitable for automotive foam mold, wooden ship model,  aviation wooden

model, rail moden mold and trains wooden mold.
Musical instrument industry: Can carve three dimension musical instrument，contour cutting;

Application:

Wood, EPS and non-metallic carbon hybrid materials.

Functional characteristics:

Adopt Europe OSAI numerical control system, high machining accuracy and high speed.

Performance Parameter:

No.

Description

Parameter

1

X,Y,Z Working Area:

2500x4000x900mm

2

Table Size:

3100×4500mm

3

X,Y,Z Traveling Positioning Accuracy:

±0.01/300mm

4

X,Y,Z repositioning accuracy:

±0.01mm

5

Table Surface:

Milling steel table (T-slot)

6

Frame:

 Welded structure (cast iron)

7

X, Y Structure:

Rack and Pinion Drive, Hiwin Rail Linear Bearings

8

Z Structure:

Hiwin Rail Linear Bearings and Ball Screw

9

Max. Power Consumption:

(Without spindle)  6.5Kw

10

Max. Rapid Travel Rate:

40000mm/min

11

Max. Working Speed:

25000mm/min

12

Spindle Power:

9.0KW

13

Spindle Speed:

0-24000RPM

14

Drive Motors:

Yaskawa servo system(Option:Siemens)

15

Working Voltage:

 AC380V/50/60Hz,3PH (Option: 220V))

16

Command Language:

G code

17

Operating System:

Syntech control System

(Option:Siemens/Osai)

18

Computer Interface:

Ethernet

19

Flash Memory:

256 M(with CF card)

20

Collet:

ER32 (BT30)

21

X,Y Resolution

 <0.01mm

22

Software Compatibility:

Type3, UcancameV9, Artcam software

23

Running Temperature:

0- 45 degree

24

Relative Humidity:

30% - 75%

25

Packing Size:

2300X4800X1900mm (in parts)

26

N.W.:

6800KG

27

G.W.:

7500KG

28

Guarantee

One year from the date of commission







29







Optional Parts

Air cooling spindle or Water cooling spindle

Dust collector

Rotary system

Mist-cooling system

Panasonic Servo motors/Delta servo motors



 Guarantee & After Sales Service
1. The machine is guaranteed for 12 months.
2. Technical support by phone, e-mail or MSN around the clock.
3. Friendly English version manual and operation video CD disk.





3 axis CNC Router for industry has several machine types. The frame adopts welded structure, very strong and stable. Optional Taiwan Syntec Control System, imported Italian air cooling spindle, Japanese Yaskawa servo motors. The constant power spindle of CNC Router is with great cutting capability and efficiency. Application for the large format machining, like nylon, fiber-board and soft metal. Custom machines are available upon request.
