Features:
The characteristics of the standard 3d scanner:
1. Portable design: Small size, small footprint, no noise, easy to disassembly and installation, very convenient to carry.
2. "One-click" mark all points automatic splicing: Automatic splicing times of scanning data, the process is complete
with “one-click”. Without manual intervention, no third party software, to ensure that the data does not appear
stratifiedphenomenon.
3. Non-contact scanning: Measurement without contact with anything, can easily measure the soft, easy to
deformation objects;And can be move scanner when scanning large heavy objects, there is no limit to the trip.
4. The noise of the point cloud processing and trim: Can pruning and eliminate noise during scanning and at the
end of the scanning. Due to use of high-end industrial lenses and original software de-noising module, can
overcome the domestic like product cannot solve noise and floating point problem, save your post-processin
and modification time.
5. Standard 3d scanner, its single scanning range is bigger, the corresponding point distance is thin, suitable for decorative
pattern delicate degree requirements is not particularly high, under the condition of product is bigger, use with photogravimetric
system canbe auto vehicle scanning.
Performance parameters:
Product Model |
Standard 3d scanner |
|
single scanning range |
400X300 |
200X150 |
Single measuring accuracy |
0.015~0.025 |
|
Scan dot pitch |
0.20 |
0.10 |
Object size |
400mm~1500 mm |
100 mm~400 mm |
Scanning way |
White light Photo type Non-contact |
|
Data splicing way |
The world heart automatic splicing |
|
Camera sensor |
Industrial Camera |
|
Industrial lens |
||
Grating system |
America DLP digital grating, extrapolation method of multiple frequency phase shift |
|
Grating light source |
LED cold light source, lifetime 35000 hours |
|
File format |
ASC;PLY;STL;OBJ;IGES |
|
Scanning time |
< 5S |
|
Operation system |
Windows98/NT/2000/XP/Vista/Win7 |
Guarantee & After Sales Service
1. The machine is guaranteed for 12 months.
2. Technical support by phone, e-mail or MSN around the clock.
3. Friendly English version manual and operation video CD disk.
